We offer a comprehensive range of precision metal processing equipment, including straightening, cold drawing, pointing, chamfering, cutting, thread rolling machines, and drawing dies, tailored for tube, bar, and wire materials across diverse industries.
The Automatic Hydraulic Cold Drawing Machine is a precision metal forming equipment manufactured by FangRong Precision Machinery, a company with 26 years of expertise in designing, engineering, and producing high-performance cold drawing solutions. Since its founding in 1998, FangRong has grown from a local workshop into a globally recognized manufacturer, serving customers in more than 70 countries.
The Automatic Hydraulic Cold Drawing Machine is a metal processing device that uses hydraulic power to stretch and reduce the diameter of metal materials at ambient temperature. It is designed for the cold drawing of pipes, rods, and profiles made from ferrous and non-ferrous materials, including carbon steel, stainless steel, aluminum, copper, brass, titanium, and specialty alloys. The machine is available in various models with drawing forces ranging from 50KN to 20000KN (approximately 5 to 2,000 tons), accommodating a wide spectrum of production requirements.
Step 1: Material Preparation — The raw material (hot-rolled or extruded tube/bar) is loaded onto the feed rack. One end is pointed (diameter reduced) to pass freely through the drawing die.
Step 2: Die Setup — The material is fed into the die holder, where a precision die shapes the outer diameter. For tube drawing, a mandrel or plug controls inner diameter and wall thickness.
Step 3: Hydraulic Pull — The hydraulic draw carriage, powered by an AC motor-driven hydraulic power unit, pulls the material through the die with smooth, consistent force—eliminating the vibration and surging that cause surface defects in mechanical systems.
Step 4: Intelligent Control — A programmable PLC with intuitive HMI controls the entire drawing cycle: acceleration, constant speed, deceleration, and carriage return. Real-time sensors monitor force, speed, and position, making automatic micro-adjustments to maintain set parameters.
Step 5: Finished Product — The drawn material emerges with improved mechanical properties, precise dimensions, and a superior surface finish—ready for downstream processing or final use.
What Problem It Solves
The machine solves key challenges in metal manufacturing: achieving high mechanical strength, tight dimensional tolerances, and consistent surface quality in high-volume production. Hot-rolled and extruded materials often cannot meet the requirements of applications such as hydraulic cylinders, automotive components, aerospace parts, and medical devices due to limitations in accuracy, surface finish, and material strength. Cold drawing improves material properties through work hardening and grain refinement while achieving dimensional accuracy of up to ±0.02mm. The hydraulic drive system applies controlled, stable drawing force to reduce vibration, prevent surface defects, and maintain consistent quality throughout production.
With more than 20 years of experience in cold drawing technology and thousands of drawbenches supplied worldwide, FangRong has developed solutions for a wide range of materials, including high-strength alloys and high-conductivity copper. This manufacturing experience enables us to design and build cold drawing machines adapted to different material characteristics and production requirements.
1. High-Precision Dimensional Control Advanced hydraulic transmission and closed-loop control systems ensure product diameter accuracy of ±0.02mm, far surpassing industry averages. This ultra-high precision reduces downstream machining requirements, improves sealing performance, and extends product service life.
2. Smooth, Vibration-Free Hydraulic Power Unlike mechanical systems with fixed linkages that can cause jerking and surface defects, the hydraulic system delivers fluid, controlled force from start to finish. This eliminates chatter marks, scratches, and periodic surface imperfections—critical for polished or final-finish components.
3. Wide Material Adaptability Capable of processing carbon steel, stainless steel, alloy steel, aluminum, copper, brass, bronze, titanium, nickel alloys, and specialty metals. By adjusting hydraulic pressure and speed, the machine accommodates different material hardness levels and specifications.
4. Intelligent PLC & HMI Control Programmable logic controller with an intuitive touchscreen interface allows operators to program the entire drawing cycle. Real-time monitoring and automatic adjustments ensure consistent quality with minimal operator intervention, reducing labor requirements.
5. Energy-Efficient Operation Advanced hydraulic design with variable displacement pumps and servo-proportional valves minimizes energy waste. Compared to traditional thermal processing methods, cold drawing saves considerable energy. The system only uses peak power when needed, reducing overall energy consumption.
6. Exceptional Surface Quality Uniform compression and stretching within the precision die produce smooth, flat product surfaces. This high-quality surface reduces grinding and polishing workload in subsequent processing.
7. Extended Tool Life Consistent force application and perfect alignment reduce uneven die wear, extending tool life by up to 30%. The robust construction maintains perfect alignment between the drawing carriage and die holder, crucial for product accuracy and die longevity.
8. Comprehensive Safety Features Two-hand controls, safety light curtains, and interlocked guards protect operators. CE certification ensures compliance with European Machinery Directive 2006/42/EC. Centralized controls and intuitive HMIs simplify operation and reduce setup time.
Our Automatic Hydraulic Cold Drawing Machines are available in a comprehensive range of models to suit diverse production requirements. The drawing force ranges from 50KN to 20000KN, with maximum stroke up to 25 meters and maximum drawing speeds reaching 30m/min.
All models can be customized according to customer specifications, including tube/bar diameters, materials, and production volumes. The machines feature prestressed frame type, fixed bed type, or composite type structures. Hydraulic oil tank capacity typically ranges up to 5000L depending on model. Standard electrical requirements are 380V, 50-60Hz. For ferrous metals and non-ferrous materials alike, we offer tailored solutions to meet your specific dimensional and throughput targets.
| Model / Technology parameter | FR-2T | FR-5T | FR-10T | FR-15T | FR-20T | FR-30T | FR-50T | FR-70T |
| Max. Drawing Force(KN) | 20 | 50 | 100 | 150 | 200 | 300 | 500 | 700 |
| Drawing Speed(m/min) | 0~10 | 3~10 | 3~10 | 3~10 | 3~10 | 3~10 | 2~10 | 10~16 |
| Effective Length of Finished Pipe(m) | 6 | 5 | 5 | 9 | 5 | 5 | 7 | 9 |
| Drawn Range of Outer Diameter of Finished Pipe(mm) | φ5max | φ25max | φ50max | φ60max | φ70max | φ30~φ80 | φ30~φ100 | φ30~φ100 |
| Max. Drawn Thickness of Finished Pipe(mm) | 1.5mm | 2mm | 3mm | 4mm | 5mm | 6mm | 8mm | 10mm |
| Main Oil Cylinder(mm) | φ63*φ35 | φ80*φ45 | φ125*φ70mm*3200mm | φ125*φ70 | φ150 | φ180*φ90*3000 | φ200*φ100 | φ280*φ150*9000 |
| Number of Systemic Station | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 |
| Working Pressure of System(Mpa) | 21 | 21 | 21 | 21 | 21 | 26 | 26 | 26 |
| Max. Pressure of System(Mpa) | 26.0 | 26.0 | 26.0 | 26.0 | 26.0 | 31.5 | 31.5 | 31.5 |
| Main Oil Pump(manual variable plunger pump) | 40 | 40 | 40 | 50 | 50 | 50 | 50 | 50 |
| Main Motor(KW) | 3.7 | 7.5 | 22 | 30 | 45 | 75 | 75 | 132*2 |
| Outline Dimensions(W×H×L)(m) | 1.6*1.4*30 | 1.6*1.4*30 | 1.6*1.4*30 | 1.6*1.4*30 | 1.6*1.4*30 | 1.1*1.2*20 | 1.2*1.3*25 | 1.3*1.4*25 |
| Weight(t) | 2 | 3 | 5 | 8 | 10 | 15 | 20 | 30 |
Customized specifications available upon request. Table above is for reference; actual parameters may vary by material type
| Aspect | FangRong Hydraulic System | Traditional Mechanical System |
| Force Application | Smooth, gradual, vibration-free | Jerky, with periodic surges |
| Surface Quality | No chatter marks | Prone to surface defects |
| Speed Control | Infinitely variable | Fixed gear ratios |
| Maintenance | Fewer moving parts; easier service | Complex linkages; higher wear |
| Energy Efficiency | Variable displacement pumps | Constant power consumption |
| Die Life | Up to 30% longer | Shorter due to uneven wear |
FangRong's Automatic Hydraulic Cold Drawing Machines serve a vast and diverse customer base of over 10,000 clients worldwide, spanning multiple industries and metal types:
Steel Industry (5,000+ customers)
- Carbon steel pipes and bars for construction and infrastructure
- Alloy steel components for heavy machinery and equipment
- Seamless precision tubing for hydraulic cylinders and shock absorbers
Stainless Steel Processing (2,100+ customers)
- Stainless steel tubes for food processing and pharmaceutical equipment
- Precision bars for fasteners and surgical instruments
- Corrosion-resistant components for marine and chemical applications
Copper & Brass Industry (1,800+ customers)
- Copper tubes for HVAC, refrigeration, and heat exchangers
- Copper busbars and electrical connectors
- Brass rods for plumbing fixtures and fittings
Aluminum Industry (700+ customers)
- Aluminum tubes for automotive and aerospace applications
- Aluminum bars for structural components and extrusions
- Custom profiles for architectural and industrial uses
Titanium & Specialty Alloys (500+ customers)
- Titanium tubing for aerospace hydraulic systems and medical implants
- Nickel and superalloy components for high-temperature applications
- Molybdenum, tungsten, platinum, and other precious/specialty metals
Key Application Sectors
- Aerospace: Hydraulic tubing, actuator rods, structural profiles, downhole instrumentation
- Automotive & EV: Battery cooling tubes, fuel injection lines, steering shafts
- Medical: Hypotubes, guidewires, surgical instrument blanks
- Hydraulics: Cylinder tubes, precision piston rods, bearing races
- Energy: Oil & gas control lines, valve components, heat exchanger tubes
- Electrical: Copper and aluminum busbars, connector pins
The machine is also ideal for drawing custom profiles—including hexagonal, square, oval, and other asymmetric shapes—where the steady force of hydraulics manages variable resistance.
Company Heritage & Experience FangRong Precision Machinery was founded in 1998 and has been dedicated to the design, engineering, and manufacturing of high-performance cold drawing equipment for over 26 years. We have grown from a local workshop into a globally recognized manufacturer, serving customers in more than 70 countries worldwide.
Production Capacity & Facilities We operate two modern manufacturing facilities: Dongguan Fangrong Metallurgical Equipment Co., Ltd. in Guangdong Province and Yangjiang Fangrong Machinery Co., Ltd. in Guangdong Province. Our annual production capacity exceeds 650 machines, with an average annual turnover of 45 million RMB. Dual-factory operations ensure faster delivery and optimized cost structures.
Global Reach & Testing Capabilities Our products have been exported to more than 70 countries across Europe, Asia, the Americas, and the Middle East. Every machine undergoes rigorous testing before shipment, including full-load trial runs, dimensional inspection, and performance verification to ensure compliance with customer specifications and international standards.
Comprehensive After-Sales Service We provide full-service support including installation, commissioning, operator training, and maintenance and repair services. Our global network of service partners ensures prompt response and local spare parts availability.
FangRong operates two state-of-the-art manufacturing facilities strategically located in Guangdong Province:
- Dongguan Fangrong Metallurgical Equipment Co., Ltd. — Located in Dalang Town, Dongguan City, the company's headquarters and primary manufacturing base. This facility specializes in the production of precision cold drawing machines, straightening machines, and thread rolling equipment.
- Yangjiang Fangrong Machinery Co., Ltd. — Located in Yangdong District, Yangjiang City, this facility expands our production capacity and enables faster delivery to customers.
Our manufacturing process follows a rigorous, quality-controlled workflow from order to delivery:
1. Order Confirmation & Design — Each machine is engineered to meet specific customer requirements, including tube/bar diameters, materials, and production volumes.
2. Material Procurement & Inspection — All raw materials and components are sourced from qualified suppliers and undergo incoming quality inspection.
3. Machining & Fabrication — Precision machining of critical components including the main cylinder, draw carriage, die holder, and frame structures.
4. Sub-Assembly — Assembly of hydraulic power units, control systems, and mechanical sub-systems.
5. Final Assembly — Complete machine assembly at our production line, integrating all mechanical, hydraulic, and electrical systems.
6. Electrical & PLC Integration — Installation and programming of the PLC control system with HMI interface.
7. Trial Run & Testing — Every machine undergoes full-load testing to verify drawing force, speed, accuracy, and surface quality. Dimensional accuracy is verified to ±0.05mm.
8. Quality Inspection — Final inspection by our quality control team ensures compliance with ISO9001:2015 standards and customer specifications.
9. Packaging & Shipment — Machines are securely packaged for international shipping, with containerization and export documentation.
With over two decades of manufacturing experience, FangRong maintains an uncompromising commitment to quality. Our ISO9001:2015-certified quality management system ensures that every machine leaving our factory meets the highest standards of precision, reliability, and safety.
FangRong Precision Machinery holds multiple international certifications and intellectual property rights that attest to our commitment to quality, safety, and innovation:
ISO9001:2015 Quality Management System Certification Our quality management system is certified to ISO9001:2015 standards (Certificate No.: UQ231211R1). This certification demonstrates our commitment to continuous improvement, customer satisfaction, and consistent product quality across all aspects of our operations—from design and procurement to manufacturing and after-sales service.
CE Certification Our machines comply with the European Machinery Directive 2006/42/EC, bearing the CE mark. CE certification confirms that our equipment meets the essential health, safety, and environmental protection requirements for the European market, including two-hand controls, safety light curtains, and interlocked guards.
SGS Certification Our products and manufacturing processes have been verified by SGS, a globally recognized inspection, verification, testing, and certification company. This independent validation provides our customers with additional assurance of product quality and reliability.
National Patent Certificates FangRong has been awarded over 130 patents, including 32 invention patents and more than 100 utility model patents. These patents protect our proprietary technologies in hydraulic systems, die design, automation control, and machine structure. Representative patent numbers include:
- 2013207829011
- 2008300532117
- ZL2015 2 0842922.7
Our robust intellectual property portfolio reflects our deep commitment to research, development, and technological innovation in the cold drawing industry.
Q1: What materials can the Automatic Hydraulic Cold Drawing Machine process? The machine can process a wide range of ferrous and non-ferrous metals, including carbon steel, stainless steel, alloy steel, aluminum, copper, brass, bronze, titanium, nickel alloys, molybdenum, tungsten, and precious metals. It accommodates both tubes and solid bars in various diameters and lengths.
Q2: What is the typical dimensional accuracy achieved? Our hydraulic cold drawing machines achieve dimensional accuracy of ±0.05mm, thanks to advanced hydraulic transmission systems and closed-loop PLC control.
Q3: What is the drawing force range available? We offer models with drawing forces ranging from 50KN to 20000KN (approximately 5 to 2,000 tons), with maximum stroke up to 25 meters and drawing speeds up to 30m/min. Custom specifications are available upon request.
Q4: What after-sales services do you provide? We provide comprehensive after-sales support including installation, commissioning, operator training, maintenance, and repair services. We also offer remote diagnostics and local spare parts support through our global network of service partners.
Q5: What certifications do your machines hold? Our machines are certified to ISO9001:2015 (Certificate No.: UQ231211R1), CE certified (compliant with European Machinery Directive 2006/42/EC), and SGS verified. We also hold over 130 national patents.
Q6: How long has FangRong been in the cold drawing machine business? FangRong was founded in 1998 and has been designing, engineering, and manufacturing cold drawing equipment for over 26 years. We have served more than 10,000 customers across 70+ countries.
Q7: Can the machine be customized for specific production requirements? Yes. Every machine can be customized to your specific tube/bar diameters, materials, production volumes, and automation requirements. We offer tailored solutions including integrated pointing, drawing, straightening, and cutting lines.
Q8: What is your annual production capacity? Our two factories have a combined annual production capacity of over 650 machines, with an average annual turnover of 45 million RMB. Dual-factory operations ensure faster delivery and optimized production scheduling.
Address: Dongguan Fangrong Metallurgical Equipment Co., Ltd., Dalang Town, Dongguan City, Guangdong Province, China
